Why More Isn't Better: The Science of Particle Size and Grade in Hydroxyapatite Toothpaste
|
|
Time to read 9 min
|
|
Time to read 9 min
Walk down the "clean" oral care aisle today and you'll notice a quiet arms race playing out in the ingredient lists. Brands compete on hydroxyapatite percentage. 10%, 15%, even 20%, printed large like a badge of quality. The message is simple: more must be better.
It isn't. That number is the tip of the iceberg. It's the part you can see, and the part brands want you looking at, but it's a small fraction of what actually decides whether a hydroxyapatite toothpaste works.
The things that matter most sit below the surface: how big the particles are, the grade they're made to, how the formula delivers them, and whether they stay on your teeth at all. Learning to read what's under the waterline is the difference between choosing a toothpaste on a number and choosing one that actually works.
Hydroxyapatite is the mineral that makes up roughly 97% of tooth enamel. When you use a toothpaste containing biomimetic hydroxyapatite, you're feeding your enamel more of its own native material, filling the microscopic gaps left by acid erosion and everyday wear, the way spackle fills a hairline crack in plaster. The science behind it is substantial.
A 2023 systematic review identified 62 published clinical trials on hydroxyapatite toothpastes spanning caries prevention, remineralisation, dentin hypersensitivity, gingival health and whitening, more clinical trials than any other fluoride free calcium-phosphate active studied. But how well it does that job has very little to do with the percentage on the box.
This is the detail almost nobody checks, and it's the one that decides whether the ingredient works at all.
Hydroxyapatite can only help your teeth if it can physically reach and hold onto the tooth surface. That comes down to one thing: how big the particles are. And it has two jobs to do, each with its own size limit.
The first is holding on. For the mineral to do anything, it has to bond to the enamel rather than simply rinse away, and that depends on being small enough to grip. Laboratory research using scanning electron microscopy found a clear cut-off: particles up to about 1.3 microns adhered to enamel reliably, while anything larger didn't.³ An oversized particle doesn't help no matter how much of it there is. If it can't attach, it can't work.
The second is easing sensitivity. That twinge from something hot or cold comes from microscopic channels in the tooth called dentin tubules. They're widest deep inside the tooth (around 2.5 microns) and narrow as they reach the surface, down to roughly 0.9 to 1.2 microns at the exposed edge where you actually feel it. To calm it, a particle has to be small enough to slip into and seal those openings.
Here's where the label "micro-hydroxyapatite" falls short: it isn't a precise measurement. Conventional, lower-grade micro-HAp can be as large as 5 microns, too big to bond to enamel, and far too big to enter a tubule at the surface. At that size it can't do either job, no matter how high the percentage on the box.
This is exactly why we engineer ours to 1.1 microns: small enough to bond to enamel, comfortably under the 1.3-micron threshold, and small enough to enter the tubule openings where sensitivity starts. Not "micro" as a marketing word, but a specific, deliberate size chosen to do both jobs. It's sourced from Maia, Portugal, to a controlled and independently documented particle-size distribution rather than to generic industrial specification.
Conventional, lower-grade micro-HAp can run as large as 5 microns, above the enamel-adhesion threshold and too large to enter a tubule at the surface. At that size it can't do either job, no matter how much of it is in the formula.
Size gets a particle to the tooth. Grade determines what else is coming along with it.
Ours is made to a documented product specification: an assay of at least 90%, total heavy metals below 20 parts per million, and a controlled particle-size distribution. It's manufactured under an ISO 9001:2015 certified quality management system and registered under the EU's REACH chemical safety framework. The specification sets the numbers; the certified system is what ensures they're hit batch after batch.
Bulk industrial hydroxyapatite isn't necessarily held to any of these standards. It can carry significantly more variable purity and a far wider, uncontrolled particle-size distribution, which means even its “micro” claim is unreliable. For an ingredient applied to the tooth surface twice a day, every day, that consistency is the point.
There's a second reason particle size matters, and it's not the one you'd expect. It's about the difference between micro and nano.
You may have seen nano-hydroxyapatite on other labels. These are much smaller particles, under 100 nanometres, and they went through nearly a decade of formal safety review in the EU. In 2023, the Scientific Committee on Consumer Safety concluded that nano-hydroxyapatite is safe in toothpaste under set conditions, and a 2025 opinion cleared it at higher concentrations again. So to be clear, this isn't a safety concern. Regulators have looked closely at nano and given it the green light.
We simply don't need it. The reason is straightforward: nano doesn't do the job any better. The research on how hydroxyapatite bonds to enamel found that particles around 1.1 microns already attach effectively, comfortably under the 1.3-micron limit where size stops making a difference. Below that point, going smaller adds nothing. You reach the same result without the nanoscale.
There's a practical upside, too. Because our micro-hydroxyapatite is larger than a "nanomaterial" (which the EU defines as 1 to 100 nanometres), it sits outside all the extra nano-specific paperwork: the special notifications, the "(nano)" labelling, the concentration limits. It's a simpler, well-understood ingredient that does exactly what it needs to, without the added complexity.
Not all hydroxyapatite is the same, and the gap is wider than you'd think. Bulk, industrial-grade hydroxyapatite comes with no purity guarantee, no controlled particle size and no manufacturing certification.
Large overseas suppliers sell it for a few dollars a kilogram, and it's the kind of material that goes into a product built to hit a bigger number, not to actually work.
Ours is a different ingredient altogether. It's made in Maia, Portugal, under ISO 9001:2015 certification, with a documented purity and particle-size specification. That control isn't cheap. Gram for gram, our hydroxyapatite costs more than half the price of silver.
That's a lot to spend on a toothpaste ingredient, and it's exactly the right place to spend it, because it buys the two things that decide whether hydroxyapatite works at all: the right particle size, and the grade to guarantee it in every batch. For something you put on your teeth twice a day, every day, that trade is worth making.
The manufacturer's recommended incorporation range for this ingredient in everyday oral care is 1% to 5%. Our Standard Range formulates within it, deliberately.
This is the part worth being clear about, because it raises the obvious question: if you use less, isn't that just cheaper? No. The binding constraint on performance is particle size and grade, not headline concentration. Get those right and a formula within the recommended range delivers consistent, high-quality mineral exposure with every brush. Pushing the percentage higher for the sake of a bigger number on the label adds cost and marketing, not performance. There are no fillers to pad a figure, and no ever-finer particles to make the number look more dramatic than the formula beneath it.
Concentration does earn its place, but as a response to need, not a marketing lever. For anyone whose enamel meets more acid in a typical day, whether from regular wine, coffee, citrus or soft drinks, we make Enamel Shield at 8%.
It's a deliberate step above the everyday range, built on the identical micro-hydroxyapatite: the same 1.1-micron particle size, the same controlled specification. More of the right mineral, matched to a genuine reason for it, not a bigger number for its own sake.
That's the whole principle in a line: get the size and grade right first, then match the concentration to the job.
Next time you compare hydroxyapatite toothpastes, the percentage on the front is the wrong question. Ask instead: what's the actual particle size, what grade is it manufactured to, where is it made, and is the rest of the formula built to let it work?
REFERENCES
1. Meyer, F., & Enax, J. (2018). Early childhood caries: Epidemiology, aetiology, and prevention. International Journal of Dentistry, 2018, 1415873.
https://doi.org/10.1155/2018/1415873
2. Limeback, H., Enax, J., & Meyer, F. (2023). Improving Oral Health with Fluoride-Free Calcium-Phosphate-Based Biomimetic Toothpastes: An Update of the Clinical Evidence.Biomimetics, 8(4), 331.
https://doi.org/10.3390/biomimetics8040331
3. Fabritius-Vilpoux, K., Enax, J., Herbig, M., Raabe, D., & Fabritius, H.-O. (2019). Quantitative affinity parameters of synthetic hydroxyapatite and enamel surfaces in vitro.Bioinspired, Biomimetic and Nanobiomaterials, 8(2), 141–153.
https://doi.org/10.1680/jbibn.18.00035
4. Garberoglio, R., & Brännström, M. (1976). Scanning electron microscopic investigation of human dentinal tubules. Archives of Oral Biology, 21(6), 355–362.
https://doi.org/10.1016/S0003-9969(76)80003-9 (PubMed: https://pubmed.ncbi.nlm.nih.gov/1066114/)
5. Fluidinova, S.A. nanoXIM•CarePowder Technical Data Sheet (Rev. 03/10/2023).
https://cdn.prod.website-files.com/6571fd01f1580d98aad1dc89/65834b8992c584861340103d_nanoXIM%E2%80%A2CarePowder_TDS.pdf
6. SCCS. Final Opinion on Hydroxyapatite (nano), SCCS/1648/22, adopted 21–22 March 2023.
https://health.ec.europa.eu/system/files/2023-03/sccs_o_269.pdf
7. SCCS. Opinion on Hydroxyapatite (nano) — Submission IV, SCCS/1677/25, 1 July 2025 (safe up to 29.5% in toothpaste).
https://health.ec.europa.eu/publications/sccs-scientific-opinion-hydroxyapatite-nano-submission-iv_en
8. Commission Regulation (EU) 2024/858 of 14 March 2024.
https://eur-lex.europa.eu/eli/reg/2024/858/oj
